Load Testing a WooCommerce Site: A K6 Case Study

Introduction

In Part 1 of this series, we fixed critical migration bugs that were preventing our client’s WooCommerce site from functioning properly. The database corruption was resolved, memory limits were increased, and all plugin conflicts were eliminated.

But the site was still painfully slow – 15-20+ seconds to load pages, with frequent timeouts under even moderate traffic.

Before we could optimise performance, we needed to measure it objectively. This is where load testing comes in.

In this post, we’ll cover:

Why load testing is essential before optimisation
Setting up Grafana K6 for WooCommerce testing
Creating realistic test scenarios
Running tests with 5, 10, 20, and 40 concurrent users
The “double-slash bug” that skewed our initial results
Shocking performance metrics that revealed the true problem

Why Load Testing Matters

You can’t optimise what you can’t measure. Without objective data, you’re just guessing.
Common mistakes we see:

“It feels slow” – Subjective, not actionable
“PageSpeed Insights says…” – Tests empty cache, single user, doesn’t reflect real usage
“Works fine for me” – Your local network and empty browser cache don’t represent real users
“We added caching, should be better” – Did you verify? By how much?

What load testing reveals:

How your site performs under concurrent users (not just one)
Where bottlenecks appear as load increases
Which pages/features break first under pressure
Objective metrics you can track over time
Before/after comparisons to prove optimisations work

Real-world example:
Our client’s site loaded in 3 seconds for a single user, but with 10 concurrent users, the average response time jumped to 20+ seconds. Without load testing, we never would have discovered this.

Choosing a Load Testing Tool: Why K6?

We chose Grafana K6 for several reasons:
Why K6:

✅ Open source – Free to use
✅ JavaScript-based – Easy to write test scenarios
✅ Realistic load – Simulates real browser behaviour
✅ Detailed metrics – Response times, error rates, throughput
✅ Flexible – Can test specific pages, user flows, API endpoints
✅ Cloud or local – Run on your machine or cloud servers

Alternatives we considered:

Apache JMeter – More complex, GUI-based, heavier resource usage
Locust – Python-based, good for API testing
Artillery – Similar to K6, but with less detailed metrics
Loader.io – Cloud-based, costs money for serious testing

For WooCommerce specifically, K6 offered the best balance of power and simplicity.

Setting Up K6

Installation
K6 installation is straightforward:
On Mac:


[bash]
brew install k6

On Ubuntu/Debian:


[bash]
sudo gpg -k
sudo gpg --no-default-keyring --keyring /usr/share/keyrings/k6-archive-keyring.gpg --keyserver hkp://keyserver.ubuntu.com:80 --recv-keys C5AD17C747E3415A3642D57D77C6C491D6AC1D69
echo "deb [signed-by=/usr/share/keyrings/k6-archive-keyring.gpg] https://dl.k6.io/deb stable main" | sudo tee /etc/apt/sources.list.d/k6.list
sudo apt-get update
sudo apt-get install k6

On Windows:


[bash]
choco install k6

Verify installation:


[bash]
k6 version

You should see output like:

Our Testing Strategy

We needed to test the site under realistic conditions that mimic actual user behavior.

Test Scenarios We Created

1. Homepage Load Test

Simulates users landing on the homepage
Test the hero slider, featured products, and navigation

2. Shop Page with Filters

Most resource-intensive page
Test product queries with multiple filters
Critical for e-commerce user experience

3. Single Product Page

Tests individual product rendering
Includes images, variations, and related products

4. Complete User Journey

Homepage → Shop → Filter → Product → Add to Cart
Most realistic scenario

Load Levels

We tested at increasing concurrent user levels:

5 users – Baseline, light traffic
10 users – Moderate traffic, typical for small stores
20 users – Heavy traffic, peak hours
40 users – Stress test, Black Friday / flash sale levels

Why these numbers?

In load testing, 1 virtual user ≈ 20-30 real users because:

Real users have think time (reading, browsing)
Real users don’t all click at the exact same moment
K6 virtual users make continuous requests without pausing

So, 10 virtual users ≈ 200-300 real users are browsing your site.

Creating Our First K6 Test

Test 1: Homepage Load Test

Here’s our first K6 script to test the homepage:


[JavaScript]
import http from 'k6/http';
import { check, sleep } from 'k6';

export const options = {
  stages: [
    { duration: '2m', target: 5 },   // Ramp up to 5 users
    { duration: '2m', target: 10 },  // Ramp up to 10 users
    { duration: '2m', target: 20 },  // Ramp up to 20 users
    { duration: '2m', target: 40 },  // Ramp up to 40 users
    { duration: '2m', target: 0 },   // Ramp down to 0
  ],
  thresholds: {
    http_req_duration: ['p(95)<5000'],  // 95% of requests under 5s
    http_req_failed: ['rate<0.10'],     // Less than 10% errors   }, }; let BASE_URL = 'https://newstage.adnart.com'; export default function () {   const res = http.get(`${BASE_URL}/`, {     headers: { 'Cache-Control': 'no-cache' },     timeout: '30s',   });   check(res, {     'status is 200': (r) => r.status === 200,
    'response time < 5s': (r) => r.timings.duration < 5000,     'body returned': (r) => r.body.length > 0,
  });

  sleep(1);  // Think time between requests
}

Key Elements Explained:

Stages – Gradual ramp-up of users:

Start with 5 users for 2 minutes
Increase to 10 users for 2 minutes
Continue ramping to 20, then 40 users
Ramp down to 0 (cool-down period)

Thresholds – Pass/fail criteria:

p(95)<5000 – 95% of requests must complete in under 5 seconds
rate<0.10 – Error rate must be under 10%

Checks – Validate each response:

Status code is 200 (success)
Response time is under 5 seconds
Body content was returned

Sleep – Simulates user “think time” between actions

Running the First Test

Save the script as and run:


[bash]
k6 run homepage-test.js
```

**What you'll see:**

K6 outputs real-time metrics:
```
     ✓ status is 200
     ✓ response time < 5s
     ✓ body returned

     checks.........................: 100.00% ✓ 180    ✗ 0
     data_received..................: 30 MB   500 kB/s
     data_sent......................: 15 kB   250 B/s
     http_req_duration..............: avg=3.2s min=1.1s med=2.9s max=8.5s p(90)=5.2s p(95)=6.1s
     http_req_failed................: 0.00%   ✓ 0      ✗ 60
     http_reqs......................: 60      1/s
     iterations.....................: 60      1/s
     vus............................: 40      min=5    max=40

Test 2: Shop Page with Filters

The shop page with product filtering was the most critical to test:


[JavaScript]
import http from 'k6/http';
import { check, sleep } from 'k6';

export const options = {
  stages: [
    { duration: '30s', target: 10 },
    { duration: '1m', target: 10 },
    { duration: '30s', target: 0 },
  ],
  thresholds: {
    http_req_duration: ['p(95)<5000'],   }, }; let BASE_URL = 'https://newstage.adnart.com'; const FILTER_URLS = [   '/shop/?orderby=popularity',   '/shop/?orderby=popularity&filter_color-catgories=black',   '/shop/?orderby=popularity&filter_finish=matte-finish',   '/shop/?orderby=popularity&filter_capacity=20-oz-25-oz',   '/shop/?orderby=popularity&filter_color-catgories=black&filter_finish=soft-touch', ]; function randomItem(arr) {   return arr[Math.floor(Math.random() * arr.length)]; } export default function () {   const url = `${BASE_URL}${randomItem(FILTER_URLS)}`;      const res = http.get(url, {      timeout: '30s',     tags: { page_type: 'shop_filter' }   });      check(res, {     'status is 200': (r) => r.status === 200,
    'response < 5s': (r) => r.timings.duration < 5000,     'has products': (r) => r.body.includes('product'),
  });

  sleep(2);  // Users spend more time on shop page
}

What’s Different:

Shorter test – 30s ramp up, 1 minute sustained, 30s ramp down
Random URLs – Simulates users applying different filters
Tags – Label metrics by page type for better analysis
Longer sleep – 2 seconds to simulate browsing behavior
Custom check – Verifies products are actually rendered

Running the Shop Filter Test


[bash]
k6 run shop-filter-test.js
```

---

## Initial Test Results: The Disaster

Our first complete test run revealed shocking metrics:
```
THRESHOLDS
     ✗ http_req_duration..............: p(95)=23.72s

RESULTS
     checks_total...................: 556
     checks_succeeded...............: 76.64%  ✓ 426   ✗ 130
     checks_failed..................: 23.27%

HTTP METRICS
     http_req_duration..............: avg=7.67s  med=5.2s  max=30s  p(95)=23.72s
     http_req_failed................: 11.65%  ✓ 130   ✗ 985
     http_reqs......................: 1,115   18.5/s

ERRORS
     timeouts.......................: 130 requests timed out
     error_rate.....................: 23.27%
```

**Translation:**

* ❌ **23% error rate** - Nearly 1 in 4 requests failed
* ❌ **23.72 seconds** - 95th percentile response time
* ❌ **130 timeouts** - Requests that took over 30 seconds
* ❌ **11.65% HTTP failures** - Server errors, connection issues

**This was worse than we expected.**

---

## The Double-Slash Bug Discovery

While analysing the failed requests, we noticed something odd in the error logs:
```
WARN: Get "https://newstage.adnart.com//shop/?orderby=popularity": 301 redirect
WARN: Get "https://newstage.adnart.com//product-category/barware/": 301 redirect

Notice the double slash () after the domain?

What Went Wrong

Our K6 scripts had:


[JavaScript]
let BASE_URL = 'https://newstage.adnart.com/';  // Trailing slash!

// Later in code:
const url = `${BASE_URL}/shop/`;  // Leading slash!

// Result: https://newstage.adnart.com//shop/

This caused:

301 redirect on every request (doubled the server load)
Skewed metrics – We were measuring redirect time + page load time
Extra database queries – WordPress processed each URL twice

The Fix

Simple but critical:


[javascript]
// Remove trailing slash from BASE_URL
let BASE_URL = 'https://newstage.adnart.com';
BASE_URL = BASE_URL.replace(/\/$/, '');  // Safety check

// Now URLs are correct:
// BASE_URL + '/shop/' = 'https://newstage.adnart.com/shop/' ✅
```

**Lesson learned:** Always validate your test URLs before running large-scale tests!

---

## Re-Testing After the Fix

We fixed the double-slash bug and re-ran the tests:
```
RESULTS (After URL Fix)
     http_req_duration..............: avg=11.29s  p(95)=30s
     http_req_failed................: 5.93%
     error_rate.....................: 5.93%
     timeouts.......................: 50 (down from 130)

Better, but still terrible:

✅ Error rate dropped from 23% to 6%
✅ Timeouts reduced by 60%
❌ Still averaging 11+ seconds per request
❌ 95th percentile still hitting 30-second timeout

The site was functional, but completely unusable under load.

What the Tests Revealed

Key Findings from Load Testing

1. Single User vs. Concurrent Users

1 user: 3-4 seconds (acceptable)
10 users: 11 seconds average (terrible)
40 users: 20+ seconds, frequent timeouts (broken)

Performance degradation was exponential, not linear.

2. Shop Filters Were the Killer

Homepage: 4-6 seconds under load
Simple product page: 5-8 seconds
Shop with 2+ filters: 20-30 seconds ← The problem

3. Database Was the Bottleneck

Monitoring server resources during tests:


[bash]
# CPU usage: 30-40% (plenty of headroom)
# RAM usage: 8GB / 16GB (50%, not the issue)
# Disk I/O: Normal
# Database connections: MAXED OUT at 150

The database was drowning in queries.

4. Error Patterns

Most errors occurred:

During filter queries with 3+ filters
When multiple users hit the shop page simultaneously
After 2-3 minutes of sustained load (connection pool exhaustion)

Test Metrics Explained

Understanding K6 Output

http_req_duration – Total request time:

avg – Average time across all requests
med – Median (50th percentile)
p(90) – 90th percentile (90% of requests faster than this)
p(95) – 95th percentile (our threshold)

http_req_failed – Percentage of failed requests:

HTTP errors (500, 502, 503, 504)
Timeouts
Connection failures

iterations – Complete test cycles:

How many times the script ran completely
Higher is better (means requests completed)

vus – Virtual users:

Current number of simulated users
min and max show the range during test

Creating a Monitoring Dashboard

To track metrics over time, we created a simple monitoring script:


[bash]
#!/bin/bash
# monitor-during-test.sh

echo "Starting monitoring..."

while true; do
    echo "=== $(date) ==="

    # Server load
    uptime

    # Database connections
    mysql -e "SHOW STATUS LIKE 'Threads_connected';"

    # PHP-FPM status
    ps aux | grep php-fpm | wc -l

    # Memory usage
    free -h | grep Mem

    echo "---"
    sleep 10
done

Run this in a separate terminal during K6 tests to correlate performance with server metrics.
